KSL-80 is a super-duty fused white corundum-based castable with nano-sized bonding agents and minimal impurities. This product is engineered for ultimate corrosion and erosion resistance in extreme environments such as glass tank regenerators and carbon black reactors.
Technical Specifications
| Property | Value |
|---|---|
| Al₂O₃ Content (%) ≥ | 80 |
| Bulk Density (g/cm³, 110℃×24h) ≥ | 2.65 |
| Cold Crushing Strength (MPa, 110℃×24h) | 70 |
| Flexural Strength (MPa) | |
| └─ 110℃×24h | 3.0 |
| └─ 1300℃×3h | 5.0 |
| Heating Permanent Line Change (%) | -1.0 ~ +0.5 (1500℃×3h) |
| Plasticity Index (%) | 12 ~ 35 |
| Moisture Content (%) ≤ | 10.0 |
Key Features
Exceptional purity and thermal shock stability
Ultra-low impurity content (Fe₂O₃ < 0.2%)
Suitable for direct contact with molten glass or metal
Extremely low linear change upon heating
Typical Applications
Glass furnace superstructure
Petrochemical riser linings
Titanium dioxide calciners
Hydrogenation reactors
Production Details
Made with fully sintered white fused alumina and reactive microsilica. Tailor-made for ultra-demanding conditions.
Packing and Shipping Details
Packaging Type: 25kg or 50kg per moisture-resistant kraft bag
Palletized Load: Wrapped in PE film for moisture protection
Container Loading: Available in 20ft or 40ft containers
Delivery Time: 15–30 working days after order confirmation
Storage: Keep in a dry place; shelf life up to 6 months
Frequently Asked Questions (FAQ)
Q1: Is it suitable for contact with molten metal?
Yes, it offers high resistance to molten aluminum and glass.
Q2: Any risk of contamination?
Very low—ideal for high-purity applications.
Q3. Can it be installed with gunning machine?
Gunning grade available upon request.
Q4: Is it self-flowing?
Standard version is vibratable; self-flowing mix can be provided.
Q5: Is this product acid-resistant?
Yes, especially in non-basic environments.
